API 587: UT qualification for in-service damage

The timely detection of degradation mechanisms in industrial equipment depends heavily on the precision of ultrasonic testing (UT). To strengthen this link, the American Petroleum Institute developed Recommended Practice API 587, a standard designed to qualify UT examiners focused on damage generated exclusively during service.

Unlike other regulations oriented toward equipment design or the physical methodology of the test, API 587 seeks to guarantee that personnel possess demonstrable competencies to identify complex degradation in pressure vessels, piping, and critical assets. Its correct application directly impacts equipment reliability, operational safety, and the mechanical integrity of high-risk industries.

What is API 587 and why does it complement traditional certification?

API 587 is a technical document specifically oriented toward defining the minimum competencies required of personnel performing ultrasonic testing on assets subjected to operational degradation. The standard recognizes a critical reality in the field: the effectiveness of UT inspection does not depend solely on the sophistication of the equipment used, but rather on the inspector’s ability to interpret complex ultrasonic signals associated with material degradation.

It is fundamental to understand that API 587 does not replace conventional certification based on general standards such as ASNT SNT-TC-1A or ISO 9712. Instead, it acts as a specialization complement.

An inspector may hold a current certification as a UT Level II or Level III and yet lack the metallurgical or operational training to evaluate complex in-service degradation mechanisms. API 587 intervenes precisely to close that technical gap, requiring the examiner to demonstrate knowledge that links the physical process, basic metallurgy, and the ultrasonic response.

Here is the translation of the content into English, maintaining all paragraphs and structural formatting as requested:

Requirements and Scope of API 587

Recommended Practice API 587 redefines the evaluation of ultrasonic testing (UT) personnel, shifting the focus from theoretical or documentary knowledge toward a framework based strictly on practical performance and field analysis capabilities.

What does API 587 require of the UT examiner?

The standard requires the inspector to demonstrate specific competencies to detect in-service damage, going beyond the simple operation of the equipment. To achieve this, two pillars must be met:

• Interconnected Normative Knowledge: It is mandatory to understand how API 587 relates to other industry codes, principally API 571 (damage mechanisms), in addition to inspection and fitness-for-service codes such as API 510, 570, 653, API RP 577, and 579.
• Integrated Analysis Capability: The examiner does not merely report signals; they must possess the technical judgment to correlate service history, operating conditions, and equipment materials with the results observed on the ultrasonic screen.

Qualification process and impact on reliability

To implement API 587 effectively, companies must abandon purely theoretical evaluation models and follow a structured process that includes:

[Define Technical Profiles] ➔ [API 587/571 Training] ➔ [Practical Evaluation Using Real Defects] ➔ [Continuous Monitoring and Auditing].

The structured qualification process

To effectively qualify a UT examiner in the detection of in-service damage, API 587 establishes a structured approach divided into four consecutive stages:

1. Definition of the Technical Profile: Initial phase

Organizations must establish specific profiles based on the type of plant equipment, the required UT techniques (such as PAUT or TOFD), and the criticality of the damage mechanisms expected in the process.

2. Specialized training: Theoretical formation

The candidate receives training focused on the relationship between API 587 and the damage mechanisms described in the API 571 standard, acquiring notions of applied metallurgy, mechanical integrity, and real case analysis.

3. Practical Performance Evaluation: Field validation

Practical tests are conducted using specimens that present real or simulated defects (such as localized corrosion or fatigue cracks). The accuracy of the A-Scan interpretation, the repeatability of the results, and the selection of the ideal technique are evaluated.

4. Continuous monitoring and audit: Maintenance of competence

Qualification is not static; it requires periodic retraining, technical audits of field reports, and updates as inspection technologies evolve.

The practical evaluation focuses on actual performance against critical mechanisms such as cracking, localized corrosion, HIC (hydrogen-induced cracking), creep, and fatigue. The approval criteria measure the accuracy of interpretation, the selection of the appropriate technique, and the repeatability of results.

The direct benefit: By elevating the rigor of personnel qualification, plants optimize their mechanical integrity programs, drastically reduce misdiagnoses, decrease operational risks, and achieve a safe extension of the useful life of their critical assets.

Basic certification vs. API 587 qualification

Key Difference: Basic Certification vs. API 587 Qualification

The industry often confuses these two concepts, but the text establishes a very clear boundary:

• Conventional Certification (ASNT SNT-TC-1A / ISO 9712): Validates that the technician knows the physical principles of ultrasound, knows how to configure the equipment, detects generic discontinuities, and prepares basic reports.
• API 587 Qualification: This is a higher level of specialization. It validates that the inspector knows how to interpret complex operational degradation signals, understands the general mechanical integrity of the asset, and can make sound technical decisions under risk conditions.

To understand the scope of this standard, it is useful to contrast the objectives of a traditional certification against the specialized requirements of Recommended Practice API 587:

Aspect	Basic UT Certification (ASNT / ISO 9712)	Specialized API 587 Qualification
Primary Focus	Validation of physical principles of ultrasound and general equipment operation.	Evaluation of competence applied to the integrity of in-service assets.
Evaluated Skills	Calibration, basic instrument configuration, and detection of generic discontinuities.	Identification of specific degradation mechanisms and interpretation of complex signals.
Technical Context	Preparation of reports based on the presence or absence of indications.	Correlation of UT results with operating conditions and equipment history.
Normative Base	General codes for non-destructive testing.	Direct synergy with integrity codes such as API 571, 510, 570, and 653.

Critical in service damage evaluated by ultrasonic testing

Operational damage mechanisms represent one of the greatest challenges for modern industrial inspection because they degrade materials in a localized or oriented manner, producing patterns that can easily be confused with one another. Examiners qualified under API 587 must be able to accurately identify phenomena such as:

• Hydrogen-Induced Cracking (HIC / WFMT): Hydrogen can generate microcracks and internal laminations in wet environments with the presence of H2​S. These discontinuities are difficult to detect using conventional techniques and require a high-sensitivity UT scan for correct sizing.
• Thermal fatigue: Repetitive temperature cycles produce progressive cracking in zones subjected to constant expansion and contraction. The inspector must understand how the morphology of these cracks alters and scatters ultrasonic signals.
• High-temperature creep: In equipment exposed to prolonged thermal services, creep damage evolves from microvoids to macrocracks. Advanced ultrasonic inspection allows for the identification of this microstructural degradation before a catastrophic failure occurs.
• Internal weld defects and operational discontinuities: Beyond native manufacturing flaws (such as lack of fusion, porosity, or slag inclusions), the inspector must apply their skill to accurately locate and record the height, depth, and length of defects that have grown or become active due to service stresses.

Benefits and integration with the API ecosystem

The adoption of API 587 allows for a native integration with Risk-Based Inspection (RBI) programs and Fitness-For-Service assessments. A qualified examiner does not work in isolation: they correlate operating conditions and equipment history with the instrument results.

This drastically reduces misdiagnoses (false positives or negatives), optimizes costs by avoiding unnecessary repairs or unplanned shutdowns, and provides highly reliable data for remaining useful life calculations required by codes API 510 (pressure vessels), API 570 (piping), and API 579-1/ASME FFS-1.

The Technological factor: The shift toward advanced techniques such as Phased Array (PAUT), Time-of-Flight Diffraction (TOFD), and the Total Focusing Method (TFM) offers unprecedented spatial resolution. However, even with the support of artificial intelligence and data digitalization, human technical judgment remains the ultimate filter. API 587 maintains its relevance precisely because technology does not substitute for the inspector’s interpretative knowledge.

Conclusion

API 587 marks an indispensable standard in the professionalization of non-destructive testing applied to asset conservation. By demanding a demonstrable performance against real service degradations, it raises the reliability of inspections and transforms reactive maintenance into a robust predictive strategy. In industries where failures carry severe consequences, having UT personnel qualified under this guideline has stopped being a preferential option and has become a critical necessity for operational safety.

References

1. American Petroleum Institute. (2024). API Recommended Practice 587: Qualification of ultrasonic examination personnel for equipment and piping in the refining and petrochemical industries (3rd ed.). Washington, DC: API.
2. American Petroleum Institute. (2020). API Recommended Practice 571: Damage mechanisms affecting fixed equipment in the refining industry (3rd ed.). Washington, DC: API.
3. American Petroleum Institute. (2022). API Standard 510: Pressure vessel inspection code: In-service inspection, rating, repair, and alteration (12th ed.). Washington, DC: API.
4. American Petroleum Institute. (2022). API Standard 570: Piping inspection code: In-service inspection, rating, repair, and alteration of piping systems (5th ed.). Washington, DC: API.
5. American Society for Nondestructive Testing. (2024). SNT-TC-1A: Personnel qualification and certification in nondestructive testing (2024 ed.). Columbus, OH: ASNT.
6. International Organization for Standardization. (2021). ISO 9712:2021, Non-destructive testing, Qualification and certification of NDT personnel. Geneva: ISO.
